The Phoenix Contact MINI MCR-2-I-I-ILP is a compact, single-channel analog input isolator used to provide electrical isolation between input and output circuits. It transfers standard 0–20 mA or 4–20 mA current signals while helping reduce interference between connected devices. Its loop-powered design eliminates the need for a separate power supply, making it suitable for industrial process monitoring, instrumentation, and control systems.
| Specification | Details |
|---|---|
| Make | Phoenix Contact |
| Model | MINI MCR-2-I-I-ILP |
| Order Number | 2901994 |
| Product Name | Input Isolator |
| Product Family | MINI Analog Pro |
| Product Type | Signal Conditioner / Passive Isolator |
| Number of Channels | 1 |
| Input Signal | 0–20 mA / 4–20 mA |
| Output Signal | 0–20 mA / 4–20 mA |
| Signal Transmission | Input = Output |
| Electrical Isolation | 2-way isolation |
| Supply Voltage | 9.6–30 V DC, loop-powered |
| External Power Supply | Not required |
| Voltage Drop | 3.1 V at 20 mA |
| Maximum Output Load | Less than 600 Ω at 20 mA |
| Maximum Transmission Error | ≤ 0.1% of final value |
| Limit Frequency | 100 Hz (−3 dB) |
| Rated Insulation Voltage | 300 V AC |
| Test Voltage | 3 kV AC for 60 seconds |
| Connection Type | Screw terminal |
| Mounting | DIN rail |
| Dimensions (W × H × D) | 6.2 × 109.81 × 119.2 mm |
| Protection Rating | IP20 |
| Operating Temperature | −40°C to +70°C |
| Approvals | CE, ATEX, IECEx, UL |
| Country of Origin | Germany |
| Weight | Approx. 106 g (excluding packaging) |
