SIMRAD HALO 5000 Series is a commercial IMO/SOLAS-compliant X-band solid-state pulse-compression radar designed for professional marine navigation. The system provides up to 48 NM range, automatic target tracking, an advanced radar performance monitor and 4 ft or 6 ft open-array antenna options. Its solid-state architecture eliminates the conventional magnetron and is designed to reduce maintenance and ownership requirements.
| Specification | HALO 5000 |
|---|---|
| Manufacturer | Simrad Commercial |
| Series | HALO 5000 |
| Model | R5024 HALO5004 CAT 2 / R5024 HALO5006 CAT 2 |
| Radar Type | Solid-state pulse compression |
| Frequency Band | X-Band |
| Operating Frequency | 9.390–9.495 GHz |
| Nominal Peak Power | 130 W |
| Antenna | End-fed slotted waveguide |
| Antenna Sizes | 4 ft / 6 ft |
| Maximum Range Scale | 48 NM |
| Antenna Speed | 22 or 44 RPM |
| Power Supply | 24 VDC or 110–230 VAC, 50 Hz |
| Target Tracking | Thousands of targets within 24 NM |
| Targets Displayed | Up to 100 simultaneously |
| Performance Monitor | Advanced |
| SART/RACON Detection | Approx. 3.5 NM |
| Cold Start | Approx. 40 seconds |
| Wind Resistance | Up to 100 knots |
| Sector Blanking | 4 sectors |
| IMO/SOLAS | Yes |
| Radar Display | R5000-compatible commercial display/control system |
