The Icom Incorporated IC-M85E is a compact professional handheld VHF Marine + PMR/PBR hybrid radio, designed for commercial marine operations, ports, vessels, offshore facilities, and land-based business communications. It combines marine VHF channels with programmable PMR channels in one rugged handheld unit.
| Parameter | Specification |
|---|---|
| Make | ICOM |
| Model | IC-M85E |
| Type | VHF Marine / PMR (PBR) Hybrid Handheld Transceiver |
| Marine TX Frequency | 156.000–161.450 MHz |
| Marine RX Frequency | 156.000–163.425 MHz |
| PMR/PBR Frequency | 136.000–174.000 MHz |
| PMR Channels | Up to 100 programmable channels |
| Marine Channel Spacing | 25 kHz |
| PMR Channel Spacing | 25 kHz wide / 12.5 kHz narrow |
| Output Power | 5 W / 3 W / 1 W |
| Marine Modulation | 16K0G3E |
| PMR Modulation | 16K0F3E Wide / 8K50F3E Narrow |
| Frequency Stability | ±1.5 kHz |
| Receiver Sensitivity | −4 dBμ EMF typical (20 dB SINAD) |
| Audio Output | 700 mW typical |
| Antenna Impedance | 50 Ω |
| Power Supply | 7.2 V DC nominal |
| Current Drain | Approx. 1.5 A at 5 W TX |
| Battery | BP-294 Li-Ion battery pack |
| Operating Temperature | Marine: −15°C to +55°C; PMR: −25°C to +55°C |
| Water/Dust Protection | IP67 |
| Military Standard | MIL-STD-810 |
| Dimensions | 56 × 92 × 36.2 mm with BP-294 |
| Weight | Approx. 281 g with BP-294, antenna and belt clip |
| Voice Scrambler | Built-in, 32-code |
| Emergency Functions | MOB Alarm, Man Down, Lone Worker |
| Hands-Free Operation | Internal VOX |
| Special Functions | AquaQuake, Priority Scan, Dual/Tri-watch, Monitor, Favourite Channel |
| Supplied Accessories | BP-294 battery, BC-227 rapid charger, BC-123S AC adapter, FA-SC58V antenna, MBB-3 belt clip, hand strap |
