The JRC JMR-9200 Series is a commercial marine radar system designed for vessel navigation, target detection, and collision avoidance. It is intended for professional maritime applications, offering radar configurations in both X-band and S-band to support different vessel requirements.

Key Features

Available with magnetron and solid-state scanner configurations.
26-inch wide LCD display with intuitive icon-based operation.
TT/ARPA tracking for up to 100 targets.
Standard AIS display for up to 500 targets, expandable to 1,000 with an optional license.
Safety Zone Viewer to highlight collision-risk areas.
Optional chart radar and wave-analysis functions.
IMO performance-standard compliance and MED certification for applicable configurations.

Technical Specification

Parameter	Specification
Manufacturer	Japan Radio Co., Ltd. (JRC)
Series	JMR-9200
Equipment Type	IMO Marine Radar
Radar Band	X-Band / S-Band
X-Band Frequency	9,410 MHz ± 30 MHz
S-Band Frequency	3,050 MHz ± 20 MHz
Transmitter Output	10 kW / 25 kW / 30 kW magnetron; 250 W / 600 W solid-state, depending on model
Maximum Range Scale	96 NM
Minimum Range Scale	0.125 NM
Display	26-inch wide color LCD
Display Resolution	1920 × 1200 pixels (WUXGA)
Antenna Length	6 ft, 7 ft, 9 ft or 12 ft, depending on scanner
Antenna Rotation	24 RPM, 27 RPM or 48 RPM, depending on scanner
TT/ARPA	Up to 100 targets
AIS Targets	500 standard; up to 1,000 with optional license
Target Tracking Range	Up to 32 NM
Display Modes	North-up, Course-up, Head-up
Power Supply	100–115 V AC, 220–240 V AC, or 24 V DC
Country of Origin	Japan
