The AMI R550Ni is a compact, network-enabled Automatic Identification System (AIS) receiver designed to receive AIS transmissions from nearby vessels and make the received vessel data available to compatible navigation systems through an Ethernet network. It can support maritime situational awareness by providing AIS target information to compatible onboard displays and monitoring systems.

Technical Specification

Parameter	Technical Specification
Manufacturer / Make	AMI Marine / Comar Systems
Model	R550Ni
Equipment Type	Compact Intelligent Network AIS Receiver
AIS Receiver Type	Dual-channel AIS receiver
AIS Channel A	161.975 MHz
AIS Channel B	162.025 MHz
Network Interface	Ethernet
Wireless Connectivity	Wi-Fi and Bluetooth
USB Interface	USB ports
Display Interface	HDMI
Processor	Quad-core ARM Cortex-A72
Internal Storage	16 GB eMMC
Power Supply	5 V DC via USB-C
Antenna Connector	BNC, 50 Ω
Antenna Impedance	50 Ω
Receiver Sensitivity	Better than −112 dBm
AIS Data Received	MMSI, vessel name, position, SOG, COG, heading and navigational status
Dimensions	90 × 96 × 28 mm
Weight	Approximately 130 g
Enclosure Material	ABS plastic
Ingress Protection	IP40
Operating Temperature	−15°C to +40°C
Compass Safe Distance	50 cm
