The SM Electrics le guardian 2025 is a Bridge Navigational Watch Alarm System (BNWAS) designed to monitor bridge activity and the alertness of the Officer of the Watch (OOW). If no evidence of activity or acknowledgement is received within the selected monitoring period, the system initiates a progressive alarm sequence.
The alarm sequence first alerts the OOW on the bridge using visual and audible alarms. If there is still no response, the alarm is transferred to selected backup officers’ cabins, followed by a final alarm in designated officer or public areas. The system also includes an emergency call facility for requesting immediate assistance.
| Parameter | Specification |
|---|---|
| Manufacturer | SM Electrics GmbH |
| Model | le guardian 2025 |
| Equipment Type | Bridge Navigational Watch Alarm System (BNWAS) |
| Function | Monitors bridge activity and OOW alertness |
| Basic System Part No. | 771170 |
| Operating Device | LOD 210.24.0.0 |
| Connecting Module | LCM 210.24.0.0 |
| NMEA Expansion Module | NMEA 210.24.0.0, optional |
| Operating Display | 2 × 16-character coloured illuminated display |
| Control Method | Rotary encoder with integrated push button and key switch |
| Alarm Sequence | Visual pre-alarm → Stage 1 audible alarm → Stage 2 alarm → Stage 3 final alarm |
| Emergency Call | Manual emergency call and alarm transfer facility |
| Main / Backup Supply Monitoring | Supply failure indication provided |
| Nominal Supply Voltage | 24 VDC |
| Operating Voltage Range | 18.0–31.2 VDC |
| Current Consumption | Approx. 60–400 mA; nominal approx. 120 mA for the system electronics |
| Fuse Protection | 2 × 2.0 A, 5 × 20 mm |
| Relay Contact Rating | 30 VDC, 2 A |
| Automatic Start | Via autopilot using dry contact or NMEA interface |
| Timer Reset | Reset push buttons, reset units, motion sensor and interfaced equipment |
| NMEA Interface | Bi-directional serial interface |
| VDR Interface | Available through NMEA expansion module |
| BAM / CAM Interface | Available through NMEA expansion module |
| Stage 2 Alarm Selection | Software-selectable via NMEA expansion module |
| Operating Device Dimensions | 144 × 72 × 75 mm |
| Connecting Module Dimensions | 162 × 127 × 68 mm |
| NMEA Module Dimensions | 87.1 × 127 × 68 mm |
| Compass Safe Distance | 0.60 m |
| MED Approval | MED Type Approved / Wheelmarked |
| IMO Performance Standard | IMO MSC.128(75) |
| BNWAS Standard | IEC 62616 |
| User Interface Standard | IEC 62288 |
| Environmental / EMC Standard | IEC 60945 |
| Marine Equipment Directive | Compliant with applicable EU MED requirements |
