Samyung SRG-250DN 250W MF/HF GMDSS Radiotelephone System

The Samyung SRG-250DN is a 250-Watt MF/HF radiotelephone system manufactured by Samyung ENC Co., Ltd. in South Korea. Designed for commercial ocean vessels, deep-sea fishing ships, and workboats operating in GMDSS Sea Areas A2, A3, and A4, the system provides long-range voice communications, Class A Digital Selective Calling (DSC), and Narrow Band Direct Printing (NBDP/Telex) capabilities.

Constructed with a heavy-duty aluminum chassis in a compact transceiver housing, the SRG-250DN uses advanced Digital Signal Processing (DSP) to filter atmospheric background noise and enhance incoming voice clarity. Featuring a built-in 6-channel DSC watchkeeping receiver that continuously monitors all mandatory distress frequencies, the SRG-250DN can be integrated with the SN-100 terminal, keyboard, and printer to form a complete GMDSS communications desk.

Key Features:
• SOLAS & GMDSS Class A Compliant: Meets IMO performance standards and ITU-R M.493-14 / M.541-10 recommendations for mandatory shipboard safety radiocommunications.
• 250W Transmission Power: Delivers high output signal power for extended-range communication with selectable power reduction levels (50W, 100W, 250W).
• Dedicated 6-Channel DSC Watch Receiver: Simultaneously monitors all six maritime distress and safety frequencies (2187.5, 4207.5, 6312, 8414.5, 12577, and 16804.5 kHz).
• Advanced DSP Signal Filtering: Incorporates digital filters to reduce vessel noise and improve voice reception in difficult atmospheric conditions.
• High-Visibility LCD Display: Large digital display presenting active channel, exact frequency, signal strength, and transmit/receive status.
• Integrated NBDP (Telex) Capability: Seamlessly interfaces with the SN-100 terminal unit for automated telex message processing and printing.

Technical Specification

Attribute Specification Details
Manufacturer Samyung ENC Co., Ltd.
Model / Part Number SRG-250DN
Item Type GMDSS Class A MF/HF Radiotelephone with Integrated DSC & NBDP
Output Power J3E: 250 W p.e.p. | F1B: 150 W (Selectable: 50 W / 100 W / 250 W)
Transmit Frequency 1.6 MHz – 27.5 MHz (10 Hz steps)
Receive Frequency 500 kHz – 29.99 MHz (10 Hz steps)
Channel Capacity Full ITU maritime channels plus 300 user memory channels
Emission Classes J3E (SSB Voice), F1B (NBDP/DSC), H3E (AM Rx)
DSC Watch Frequencies 2187.5, 4207.5, 6312, 8414.5, 12577, and 16804.5 kHz
Operating Power 24V DC ±15% (2.5A Receive / 30A Max Transmit)
Dimensions & Weight Transceiver: 324 (W) x 170 (H) x 347 (D) mm (approx. 8.1 kg)
Certifications & Approvals IMO GMDSS (Sea Areas A2, A3, A4), ITU-R M.493-14, RMRS Type Approved
Application Commercial shipping, ocean-going tankers, container ships, deep-sea fishing fleet
Country of Origin Republic of Korea
