$2,300.00Earn 2,300 points!
The SAMYUNG SNX-300 NAVTEX Receiver is a GMDSS-compliant marine communication device designed to automatically receive and display maritime safety information, including navigational warnings, meteorological forecasts, and distress alerts.
It is widely used on commercial vessels, offshore ships, and SOLAS-compliant installations for continuous monitoring of NAVTEX broadcasts.
| Parameter | Specification |
|---|---|
| Model | SNX-300 |
| Type | NAVTEX Receiver (GMDSS Compliant) |
| Dimensions (W×H×D) | 255 × 163 × 75 mm |
| Weight | Approx. 2.6 kg |
| Operating Temperature | -15°C to +55°C |
| Storage Temperature | -25°C to +75°C |
| Humidity | Up to 95% at 40°C |
| Power Supply | 10–36V DC |
| Power Consumption | Approx. 10–12W |
| Parameter | Specification |
|---|---|
| Frequencies | 518 kHz (International) |
| 490 kHz (National) | |
| 4209.5 kHz (HF NAVTEX) | |
| Receiving Mode | F1B (NBDP) |
| Sensitivity | ≤ 2 µV |
| Frequency Accuracy | ±10 Hz |
| Antenna Type | Active antenna (50 Ω) |
| Receiver Type | Dual-channel (simultaneous reception) |
| Parameter | Specification |
|---|---|
| Display Type | LCD |
| Screen Size | 5.6 inch |
| Resolution | 320 × 240 pixels |
| Brightness | Adjustable |
| Contrast | Adjustable |
| Functions | Message display, storage, filtering, alarm |
| Parameter | Specification |
|---|---|
| Memory Capacity | ~1.6 million characters |
| Messages Stored | 200+ per channel |
| Permanent Storage | 50 messages per channel |
| Storage Duration | Up to 72 hours |
| Parameter | Specification |
|---|---|
| Printer Type | External thermal printer |
| Printing Speed | 52.5 cps (normal), 80 cps (condensed) |
| Character Format | 9 × 7 dot matrix |
| Parameter | Specification |
|---|---|
| Interface Standard | IEC-61162 (NMEA 0183) |
| Signal Type | RS-422 / RS-232 |
| Connectivity | ECDIS / INS / Chartplotters |
