Marinelite, VHF9000 Class A Marine VHF Radiotelephone

The Marinelite VHF9000 is a professional-grade, GMDSS-compliant Class A DSC Marine VHF Radiotelephone. It is engineered for commercial and industrial vessels that require high-reliability communication and adherence to international safety standards (IMO/CCS).

Combining a traditional physical knob with modern touchscreen operation, it serves as a central hub for bridge-to-bridge communication, distress alerting, and vessel traffic management.

  • Dual-Interface Control: Features a unique hybrid design that allows for both traditional Rotary Knob operation and Touchscreen navigation, ensuring ease of use in both calm and heavy weather.

  • Class A DSC Compliance: Equipped with a dedicated CH70 watchkeeping receiver, ensuring a constant silent watch for distress signals as required by GMDSS standards for large commercial vessels.

  • High-Clarity Audio: Features an integrated 5W internal speaker and advanced noise-cancelling technology to ensure clear voice transmission even in loud engine room or deck environments.

  • Modern Channel Support: Fully complies with MSC.1/Circ.1460/Rev.3, supporting the 4-digit channel list and all standard International, US, and Canadian channel banks.

  • Weather Alerting: Built-in weather channel receiver with automated alerting to keep the bridge informed of sudden meteorological changes.

  • BAM/INS Integration: Features a dedicated data interface for connecting to Bridge Alert Management (BAM) and Integrated Navigation Systems (INS).

Technical Specification

Category Feature Specification
General Model VHF9000 (Class A DSC)
Interface Touch Screen + Control Knob
Power Output 25 W (High) / 1 W (Low)
Frequency TX 156.000 MHz to 162.000 MHz
Frequency RX 156.000 MHz to 163.450 MHz
Performance DSC Watch Dedicated CH70 Receiver
Sensitivity $\le -120$ dBm (Main) / $\le -117$ dBm (DSC)
Audio Power $\ge 4.5$ W (at 4 ohms)
Connectivity GPS Data NMEA 0183-2.0
Interface RS422 / BAM System / INS
Antenna 50 $\Omega$ Impedance
Power Supply Voltage 12V DC ($-10\%$ to $+30\%$)
Current (TX) $\le 5.5$ A (High Power)
Physical Waterproofing IP67 (High-level protection)
Temp Range $-20$°C to $+60$°C
Certifications CCS (China Classification Society) / IMO
