Kongsberg K-Bridge ECDIS is an advanced Electronic Chart Display and Information System (ECDIS) developed by Kongsberg Maritime for commercial, offshore, and naval vessels. It is designed to support safe and efficient navigation by replacing traditional paper charts with official Electronic Navigational Charts (ENCs) while meeting all IMO and SOLAS carriage requirements.
The K-Bridge ECDIS integrates seamlessly with other bridge systems, including radar, AIS, GNSS, gyro compass, speed log, echo sounder, autopilot, BNWAS, and Voyage Data Recorder (VDR). It provides comprehensive voyage planning and route monitoring capabilities, automatic safety checks, radar overlay, anti-grounding alarms, and real-time navigation information to assist bridge officers in making informed decisions.
The system is part of the K-Bridge Integrated Navigation System (INS), enabling centralized control and information sharing across bridge workstations. It supports multiple chart formats, automatic chart updates, and complies with the latest IMO, IHO, and IEC standards, including cyber security requirements (IEC 61162-460). Its intuitive user interface, high-resolution displays, and configurable layouts improve situational awareness and reduce operator workload, making it suitable for modern integrated bridge environments.
| Parameter | Specification |
|---|---|
| Manufacturer | Kongsberg Maritime |
| Model | K-Bridge ECDIS |
| Equipment Type | Electronic Chart Display and Information System (ECDIS) |
| Display Resolution | 1920 × 1200 pixels (Integrated version) / 1920 × 1080 (Standalone version) |
| Display Size | 24″ or 27″ TFT LCD (depending on configuration) |
| Power Supply | 230 VAC ±10%, 50/60 Hz ±5% |
| Power Consumption | 340 W (Integrated) / 198 W (Standalone) |
| Operating System | Windows 10 (latest software versions; earlier versions used Windows 7/XP) |
| Chart Support | IHO S-57, S-63, S-52 Presentation Library, S-64 Test Dataset |
| Chart Formats | ENC, AVCS, PRIMAR, NAVTOR, ARCS Raster Charts |
| Route Planning | Yes |
| Route Monitoring | Yes |
| Radar Overlay | Supported (Optional) |
| AIS Integration | Yes |
| Conning Integration | Yes |
| Autopilot Integration | Yes |
| BNWAS Interface | Yes |
| VDR Interface | IEC 61162-450 (LAN) / Serial NMEA |
| Network Interface | Gigabit Ethernet LAN |
| Serial Interfaces | Up to 9 serial ports (IEC 61162/NMEA) |
| Supported Sensors | GNSS/DGPS, Gyro Compass, Speed Log, Echo Sounder, AIS, Radar, NAVTEX |
| Standards Compliance | IMO MSC.232(82), IEC 61174 Ed.4.0, IEC 60945, IEC 61162 Series, IEC 62288 |
| Cyber Security | IEC 61162-460 compliant (latest versions) |
| Type Approval | DNV MED, CCS and other major Classification Societies |
| Key Features | Dual ECDIS capability, voyage recording & replay, radar overlay, automatic route checking, track control interface, multifunction display support, echo sounder monitoring, cyber-secure architecture. |
