The JMC RT-2509 is a professional, compact Class D Digital Selective Calling (DSC) Marine VHF transceiver. Manufactured by Japan Marina Co., Ltd. (JMC), it is specifically engineered for installations where space is limited but high-performance communication and safety are required.
Dual Receiver Design: Features two independent VHF receivers, including a dedicated receiver for continuous monitoring of Channel 70. This ensures you never miss a DSC alert or distress call even while communicating on another channel.
Integrated GNSS: Includes a built-in GNSS receiver that supports multiple satellite constellations, including GPS, GLONASS, and SBAS (WAAS/EGNOS/MSAS/GAGAN).
Submersible Waterproofing: Rated IPX7, allowing the unit to be submerged in water at a depth of 1 meter for up to 30 minutes.
User Interface: Equipped with a 2.4-inch full dot-matrix backlit LCD. Navigation is simplified through a rotary encoder knob for volume and squelch, plus four programmable soft-keys (F1–F4) for rapid menu access.
| Category | Feature | Specification |
| Frequencies | TX Range | 156.000 MHz – 162.525 MHz |
| RX Range | 156.000 MHz – 163.425 MHz | |
| Performance | Output Power | 25 Watts (High) / 1 Watt (Low) |
| Audio Output | $\ge$ 4.5 Watts (at 10% distortion) | |
| Channels | International, USA, Canadian, and 10 Weather channels | |
| Networking | NMEA 0183 | Input for RMC, GGA, GNS, and GLL sentences |
| GNSS | Accuracy | $\le$ 10 meters |
| Fix Time | Cold start $\le$ 60 sec; Warm start $\le$ 20 sec | |
| Physical | Dimensions | 155 (W) x 68 (H) x 86 (D) mm |
| Weight | 721g (including microphone) | |
| Temp Range | $-20$°C to $+60$°C |
