The GPSMAP® 9219 (Volvo Penta® Edition) is a premium 19-inch touchscreen chartplotter engineered as a primary hub for the Volvo Penta Glass Cockpit System. It offers a high-performance “glass bridge” experience by merging Garmin’s flagship navigation technology with deep-level integration for Volvo Penta propulsion and vessel management.
| Category | Specification |
| Physical Dimensions | 46.3 x 29.8 x 8.0 cm (18.2″ x 11.7″ x 3.1″) |
| Display Resolution | 1920 x 1080 pixels (Full HD) |
| Weight | 6.08 kg (13.4 lbs) |
| Water Rating | IPX7 |
| Power Input | 10 to 32 Vdc |
| Max Power Usage | 81 W |
| Typical Current Draw | 5.2 A (at 12 Vdc) |
Garmin BlueNet™ Ports: 2
NMEA 2000® Ports: 1
NMEA 0183 Inputs/Outputs: 1 Input / 1 Output
J1939 Port: 1 (Dedicated Volvo Penta/Engine network)
Video Inputs: 1 BNC Composite; 1 HDMI (HDCP compliant)
Video Outputs: 1 HDMI
USB Ports: 1 x USB-C
Wireless: 5 GHz Wi-Fi, Bluetooth, and ANT+
Internal Receiver: 10 Hz high-sensitivity multi-band (GPS, GLONASS, Galileo, BeiDou)
Data Storage: 2 microSD™ card slots (on the rear)
User Data: 5,000 waypoints; 100 routes; 50,000 track points
OneHelm™ Support: Centralized control for third-party systems like lighting, stabilization, and digital switching.
HDCP Compliance: Enables streaming of encrypted 1080p video across the helm network.
