The Furuno FELCOM 15 is an Inmarsat-C Mobile Earth Station (MES) designed for maritime satellite communication. It supports GMDSS-related messaging, Enhanced Group Call (EGC), data communication, vessel position reporting, and other Inmarsat-C services. The model incorporates an omnidirectional antenna and an internal 12-channel GPS receiver.
| Parameter | Specification |
|---|---|
| Manufacturer | Furuno |
| Model | FELCOM 15 |
| Equipment Type | Inmarsat-C Mobile Earth Station (MES) |
| Satellite Service | Inmarsat-C |
| Transmit Frequency | 1626.5–1646.5 MHz |
| Receive Frequency | 1530.0–1545.0 MHz |
| Antenna Type | Omnidirectional |
| G/T | Better than -23 dB/K at 5° elevation |
| EIRP | 12–16 dBW at 5° elevation |
| Modulation | BPSK |
| Modulation Rate | 1200 sps |
| Coding | Convolutional coding, rate 1/2, constraint length 7 |
| Decoding | Viterbi decoder |
| Transmission Speed | 600 bps |
| Internal GPS Receiver | 12-channel, all-in-view |
| Position Accuracy | 15 m RMS, under HDOP ≤ 4 |
| Speed Accuracy | 0.1 knot RMS |
| Navigation Data Interface | IEC 61162-1 |
| Terminal Power Supply | 12–24 VDC |
| Terminal Power Consumption – Transmit | 13.0–5.0 A |
| Terminal Power Consumption – Receive | 1.7–0.9 A |
| Optional AC/DC Rectifier | PR-240-CE |
| AC Input | 100 / 110 / 200 / 220 VAC, 1-phase, 50/60 Hz |
| Above Deck Operating Temperature | -35°C to +70°C |
| Below Deck Operating Temperature | -15°C to +55°C |
| Relative Humidity | 95% at +40°C |
| Antenna Waterproof Rating | IPX6 |
| Other Equipment Protection | IPX0 |
| Vibration Standard | IEC 60945 |
