The em-trak A200 is a high-performance Class A AIS (Automatic Identification System) transceiver designed for commercial, SOLAS, and inland waterway vessels. It provides reliable vessel identification, position reporting, target tracking, collision-awareness information, and AIS communication.
The unit features a 5-inch full-colour display, integrated Wi-Fi, NMEA 0183 and NMEA 2000 connectivity, and a high-performance GNSS receiver. The A200 uses SOTDMA technology and is designed for reliable operation in demanding marine environments. It is certified for SOLAS and Inland Waterway applications.
| Specification | Details |
|---|---|
| Manufacturer | em-trak |
| Model | A200 |
| Equipment Type | Class A AIS Transceiver |
| AIS Access Scheme | SOTDMA |
| AIS Standard | IEC 61993-2 Ed. 3 |
| Certification | SOLAS and Inland Waterway |
| Display | 5-inch full-colour LCD |
| Display Resolution | 800 × 480 pixels |
| User Interface | Rotary encoder, menu keys and direction keys |
| Night Mode | Yes |
| AIS Receiver / Transmitter | 3 Receivers / 1 Transmitter |
| AIS Transmitter Power | 12 W (+41 dBm) |
| Operating Frequency | 156.025–162.025 MHz |
| Channel Bandwidth | 25 kHz |
| AIS Receiver Sensitivity | −111 dBm (20% PER) |
| GNSS Systems | GPS, GLONASS, Galileo, BeiDou |
| GNSS Channels | 72 |
| GNSS Antenna | External antenna |
| Cold Start TTFF | Approximately 26 seconds |
| NMEA 0183 | 3 Input ports and 3 Bi-directional ports |
| NMEA 2000 | Supported |
| Wi-Fi | IEEE 802.11 a/b/g |
| Wi-Fi Mode | Client and Access Point |
| Access Point Connections | Up to 5 connections |
| SD Card Interface | Micro SD card |
| Supply Voltage | 12 V or 24 V DC |
| Operating Voltage Range | 9.6–31.2 V DC |
| Average Power Consumption | 6.2 W at 12 V DC |
| Average Current | 520 mA at 12 V DC |
| Peak Current | Up to 6 A |
| Operating Temperature | −25°C to +55°C |
| Storage Temperature | −25°C to +70°C |
| Ingress Protection | IPX6 / IPX7 |
| Dimensions (W × H × D) | 152 × 165 × 95 mm |
| Weight | Approximately 1.1 kg |
| VHF Antenna Connector | SO-239 |
| GNSS Antenna Connector | TNC |
| VHF Antenna Frequency Range | 156.025–162.025 MHz |
| Power Connector | 2-way circular multipole |
| Data Connector | 14-way circular multipole |
| Galvanic Isolation | NMEA 0183, NMEA 2000, power supply and VHF antenna port |
