The SKIPPER ESN100 is a navigation Echo Sounder with a black box and a 9″ touch display. The Echo Sounder graphics are continuously shown on the screen along with complete navigational details. Most of the functions are automatic.
| Parameter | Specification |
|---|---|
| System Type | IMO Wheelmarked navigation echo sounder |
| Display Unit | 9-inch color touchscreen |
| Resolution | High-visibility marine display (touch interface) |
| Frequency | 50 kHz / 200 kHz (selectable) |
| Transducer System | Single active channel (one frequency at a time) |
| Dual Transducer Option | 2 transducers can be installed, but only one active at a time |
| Depth Range | 0 – 1000 m selectable |
| Depth Accuracy | < 1% error |
| Power Output | Approx. 700 W (nominal), >1000 W peak capability |
| Gain Control | Auto / Manual |
| TVG (Time Var. Gain) | Auto / Manual |
| Range Control | Auto / Manual |
| Power Control | Auto / Manual |
| Display Modes | Real-time echo, navigation view, alarm display |
| Memory (History) | Up to 24 hours of depth data storage |
| Logging Output | Network-based external logging support |
| Alarm System | Depth alarm, system alarm, IEC/IMO compliant alarms (ALR/ALF) |
| Alarm Standard | IEC 62923 / BAM compatible |
| Inputs | NMEA 0183 (GPS, speed, draft, gyro inputs) |
| Outputs | NMEA 0183 (DBS, DBK, DPT, ALR, ALF) |
| Interface | LAN + serial communication (IEC 61162) |
| Power Supply (Control Unit) | 10–32 V DC |
| Power Supply (Transceiver Unit) | 21–36 V DC |
| Operating Mode | Fully automatic / semi-manual |
| Display Functions | Depth, seabed echo, alarm status, navigation overlay |
| Installation Setup | Black box system + remote display |
| Environmental Standard | IMO + IEC marine equipment standards |
| Certification | IMO Wheelmark (MED-B approved) |
| Typical Accuracy Range | 1 m to 1000 m depth coverage |
| System Architecture | Modular (display + transceiver + transducer) |
