$900.00Earn 900 points!
The Tengfei 2-in-14-out NMEA Buffer (Model: UMJN-BUF2N14) is a high-capacity distribution amplifier designed for complex bridge systems. It allows for redundant data sources (like two separate GPS units) to feed up to 14 different listeners, ensuring that even if one sensor fails, the entire navigation network remains functional.
| Feature | Specification |
| Input Channels | 2x High-sensitivity ports (Opto-isolated) |
| Output Channels | 14x Independent high-power ports |
| Output Formats | 12x NMEA 0183 (RS422) + 2x RS485 |
| Baud Rate Support | 2,400 to 115,200 bps (Independent per channel) |
| Power Supply | DC 24V (Range: 18V – 36V) |
| Protections | Over-voltage (36V), Surge, Reverse Polarity, Electronic Fuse |
| Operating Temp | -15°C to +55°C |
| Dimensions | 208 x 152 x 46.5 mm |
