$3,600.00Earn 3,600 points!
The XN60BD (21.5″) is a massive, professional-grade Multi-Function Display (MFD) built on a high-performance Android 5.1 platform. It features a Full HD capacitive multi-touch screen with 1000-nit max brightness, ensuring perfect visibility in direct sunlight. This unit acts as the “Command Center” for a vessel, integrating navigation, surveillance, and vessel monitoring into a single expansive interface.
| Feature | Specification |
| Display | 21.5-inch Capacitive Multi-touch Screen |
| Resolution | 1920 x 1080 (Full HD) |
| Brightness | Up to 1000 cd/m² (Sunlight Readable) |
| Processor | Cortex-A17 Quad-core (1.8GHz) |
| Memory / Storage | 4GB RAM / 32GB Flash Internal |
| Positioning | BDS High-Precision & GPS Dual-mode |
| Position Accuracy | < 10cm (Horizontal) / < 15cm (Vertical) |
| AIS Function | Built-in Class B AIS Transceiver (2W) |
| Networking | 4G (LTE), WiFi, Bluetooth 4.0, Gigabit Ethernet |
| Interfaces | NMEA 0183, NMEA 2000, 1080P HDMI Out |
| Video Input | Supports 6-channel IP Camera (CCTV) |
| Camera/Audio | Built-in 8MP Camera & 3W Speakers |
| Power Input | DC 18V – 36V (Consumption: ~30W) |
