$2,200.00Earn 2,200 points!
The XN60BD (12.1″) is an intelligent, Android-based Multi-Function Display (MFD) that integrates GNSS navigation, electronic charting, and Class B AIS into one professional bridge unit. It features a 12.1-inch capacitive multi-touch screen with a non-air-gap design to prevent fogging. Designed for the modern “connected vessel,” it supports 4G, WiFi, and Ethernet for cloud services, OTA software updates, and remote vessel monitoring.
| Feature | Specification |
| Display | 12.1-inch Capacitive Multi-touch Screen |
| Resolution | 1024 x 768 pixels |
| Brightness | 600 cd/m² |
| Operating System | Android 5.1 (Intelligent OS) |
| Processor | Cortex-A55 Quad-core (2.0GHz, 64-bit) |
| Memory | 4GB RAM / 32GB Flash Internal Storage |
| Positioning | BDS High-Precision & GPS Dual-mode |
| Positional Accuracy | < 10cm (Horizontal) with differential corrections |
| AIS Function | Built-in Class B AIS Transponder (2W) |
| Networking | 4G (LTE), WiFi, Bluetooth 4.0, Gigabit Ethernet |
| Interfaces | 3x NMEA 0183 (2 In / 1 Configurable), NMEA 2000, HDMI (1080P) |
| Video Input | Supports 6-channel IP Camera (CCTV) with AI recognition |
| Power Input | DC 21.6V – 31.2V |
| Consumption | ~20W |
