$1,150.00Earn 1,150 points!
The XF-1069B integrates vessel identification and high-precision charting into a single rugged unit. It utilizes a 72-channel GNSS receiver (supporting GPS and Beidou) and a 2W AIS transmitter. Like the other models in this line, it features the “Dual Operating System,” allowing for a switch between Classic (professional menu-driven) and Utility (modern icon-based) modes. It is CCS (China Classification Society) type-approved, ensuring its reliability for professional maritime use.
| Feature | Specification |
| Display | 10.4-inch Color TFT LCD |
| Resolution | 800 x 600 pixels (SVGA) |
| Brightness | 300 – 400 cd/m² |
| AIS Type | Built-in Class B Transponder (Transmit & Receive) |
| AIS Power Output | 2W |
| Positioning | Dual-mode GPS L1 + BDS B1 (72-channel) |
| Position Accuracy | 2.5m (GPS+BDS); 1.0m with DGNSS |
| Memory Capacity | 50,000 Waypoints, 50,000 Markers, 500 Routes |
| Track Points | 1,000 Tracks (up to 1,600,000 points) |
| Interfaces | 1x AIS Output, 1x NMEA 0183 Out, 2x NMEA 0183 In |
| Chart Support | XINUO-MAP (Built-in) & C-MAP MAX (via SD Card) |
| Power Supply | DC 12V – 36V |
| Waterproof | IP65 (Front Panel) |
