$2,500.00Earn 2,500 points!
1 in stock
Maritime Certified: Complies with IEC 60945 and approved by major classification societies (DNV, ABS, BV, ClassNK, LRS).
Rugged & Reliable: Built to withstand vibration, humidity, and temperature variations typical on ship bridges.
High-Quality Display: 23.1″ LED-backlit MVA panel with UXGA resolution (1600×1200), wide viewing angles, high brightness (~400 cd/m²), and 16.7 million colors.
Multi-Input Support: Accepts DVI-I, VGA/RGB, and composite video signals. Picture-in-Picture (PIP) and Picture-by-Picture (PBP) features allow simultaneous display of multiple sources.
Marine Integration: Designed as a plug-and-play display for ECDIS and other bridge systems, ensuring clear chart visualization and route monitoring.
Front Panel Protection: IP66-rated for water and dust resistance; rear side IP20.
Power Flexibility: Works with both AC (115/230 V) and DC (24 V) sources common on ships.
Display size: 23.1 inch viewable diagonal (active area ~470.4 × 352.8 mm)
Resolution (native): UXGA 1600 × 1200 (4:3 aspect ratio)Pixel pitch: 0.294 × 0.294 mm
Max colors: 16.7 million
Contrast ratio: ~600:1 (typical)
Brightness: ~400 cd/m² (typical)
Viewing angles: ±85° (horizontal & vertical)
Response time: ~12 ms (black–white–black)
DVI‑I video input: 1× DVI‑I (can accept analog with adapter)
RGB (VGA) input: 1× HD‑D‑SUB 15 pin
RGB (VGA) output: 1× HD‑D‑SUB 15 pin (clone/out)
Multifunction connector: 1× 160‑pin D‑SUB (supports composite video, etc.)
USB: 1× USB Type‑B (reserved for future use)
Multi‑power input:
• AC 115/230 V (50/60 Hz)
• DC 24 V input
Typical Power Consumption: ~95 W
Max Power Consumption: ~125 W
LED backlight TFT with MVA technology for high contrast and reliability
Picture‑by‑Picture (PBP) & Picture‑in‑Picture (PIP) supported
0‑100% dimming and hotkey controls
Multifunction interface supports composite/video signal integration
IP66 front panel (dust/water protection) & IP20 rear (typical marine compliance)
Dimensions: ~584 mm (W) × 534 mm (H) × 85 mm (D)
Weight: approx. 18 kg
Operating temp.: −15 °C to +55 °C
Humidity: up to 95 % non‑condensing
Compass Safe Distance: ~1.60 m standard
Marine type approvals: IEC 60945 and approvals by major classification societies (DNV, ABS, BV, ClassNK, LRS, etc.)
ECDIS compliance (can be color calibrated for ECDIS applications)
