SCANDINAVIAN MICRO SYSTEMS, SR01-40 Gyro & LOG to NMEA Converter

Gyro Signal Converter “LR40” converts old type Gyro signals such as Synchro 360X and 90X, “Sperry Step” 6-step per deg., Anschutz Micro Step and C.Plath (Sperry) Micro Step.
NMEA HEADING & ROT OUTPUT HEADING data output as NMEA or as Course Bus, Tokimek, Yokogawa, “Lehmkuhl” LR22/40/60, Robertson SKR80/82 formats.
Speed LOG to NMEA Converter converts 200 or 400 pulses per n. mile to NMEA Speed sentence.
ALARM Signals SR01-40 has ALARM relay output: Normally Open (NO) and Normally Closed (NC) Relay Contacts and the option for NMEA alarm communication

Technical Specification

MAINS POWER
24V DC +30%, – 20% * Max 2 Watt
The SR01-40 has no ON/OFF switch.
PHYSICAL SECIFICATION
Temp. (operational): -15 deg C / +55 deg C
Physical Protection: IP22
GENERAL DESCRIPTION
The SR01-40 is a low cost, high quality unit for converting old type Gyrocompass and Speed LOG signals to NMEA. SR01-04 also computes Rate of Turn (ROT) and you can elect to output the NMEA ROT sentence in addition to the NMEA HEADING sentence
The SR01-40 can also be used as a Protocol and Baude Rate Converter.
HEADING / LOG DISPLAY
The display shows the Gyro Heading or the LOG speed as read exported on NMEA by the SR01-40. NOTE that the SR01-40 must be Aligned to the Gyro Compass Heading.

DIMENSIONS in mm
Width:190 x Height: 198 x Depth: 33
WEIGHT
Unit Net weight: 0.8 kg.
Gross Weight for Shipping: 1.0 kg
