$1,900.00Earn 1,900 points!
The EI330 uses advanced 6-axis sensing technology to provide high-precision real-time data. It is often required for compliance with IMO (International Maritime Organization) standards and is commonly used in conjunction with a Voyage Data Recorder (VDR).
Dual-Axis Monitoring: Simultaneously displays the actual angle of roll and pitch, as well as the roll period and amplitude.
Visual & Audio Alarms: Features a programmable Roll Alarm. If the vessel exceeds a pre-set safe angle, the unit triggers a visual warning and an audible alert.
Data Logging: It can record history (date, time, longitude, latitude, and angle) which is vital for accident investigation.
High-Resolution Display: Typically features an 8-inch or 10-inch color TFT LCD (depending on the specific sub-model) with a clear, color-coded interface (Port/Starboard separation).
VDR Integration: Outputs data via NMEA 0183 to the ship’s Black Box (VDR).
| Feature | Specification |
| Model | EI330 / EI330S |
| Display | 8-inch Color TFT LCD (800 x 600) |
| Angle Range | -90° to +90° (Roll and Pitch) |
| Accuracy | $\pm 0.1^\circ$ |
| Roll Period Range | 4 – 40 seconds |
| Power Supply | 24V DC (Range: 18V – 31.2V) |
| Output Protocol | NMEA 0183 (Baud rate: 4800 bps) |
| Protection | IP23 (Display Unit) / IP67 (External Sensor) |
| Certification | CCS (China Classification Society) Approved |
