SIM996 is a precision instrument designed for generating the reply echo pulse for echo sounders and fish finders.SIM996 receives the incoming pulse parameters from echo sounder/ fish finder and generates echo pulse to simulate the bottom or fish information and then sends the information back.
| Feature | Specification |
| Emission Frequencies | 24, 28, 38, 45, 50, 60, 75, 200 kHz |
| Depth Options | 6m, 12m, 24m, 48m, 96m, 192m |
| Power Supply | 8V – 25V DC |
| Power Consumption | < 1.2W |
| Dimensions | 160mm x 200mm x 75mm |
| Weight | 0.6 kg |
| Protection Rating | IPX2 |
